8.5.3 Terminal plan for the level monitoring device
Fig. :43
If the level monitoring device issues an
empty message or is not supplied with
power, the current supply to the motor is
interrupted. This ensures that no air can
enter the lines.
8.5.4 Terminal plan for the momentum sensor
Fig. 4 :4
brown
white
blue
black
+U
b
Ground
NC
-> impulse output
Identification ring
silver
brown
white
blue
black
+U
b
Ground
Identification ring
red
NC
Attention!
Signal lamp
„level OK“
34
