BEKA EP-1 User Manual

BAL_2152_EP1_Central grease lubrication pump_0816_EN EDV-Nr. 1090200430
7.5. Central lubrication pump EP-1 with integrated control unit EP-T2:
(PIN ...) = Assignment of the line socket
7.6. Central lubrication pump EP-1 and FKGGM-EP with integrated control unit EP-tronic:
(no. ...) = Cable-no. at uni-colored cables
(PIN ...) = Assignment of the line socket
brown (PIN 7)
blue (PIN 5)
- (Ground, terminal 31)
+ (Brake light, terminal 54)
green
blue
yellow
red
- (Ground, terminal 31)
+ (Ignition, terminal 15)
black (no. 5) (PIN 5)
brown (ye/gr) (PIN 7)
Intermediate lubrication
switch
orange (no. 6) (PIN 6)
red (no. 2) (PIN 2)
Signal lamp red
green (no. 1) (PIN 1)
Signal lamp green
max.
min.
Three-grade switch
for adjustment to
application conditions
External signal lamps
white (no. 3) (PIN 3)
grey (no. 4) (PIN 4)
Option
Switch for
grease level monitoring
Terminal 50 starter
and ignition
optional
Option
Ignition release
Option
Collective
malfunction
report
black
blue
blue
black
Proximity
switch
for stroke
control
Option
Micro switch for
pressure relief valve
monitoring
+
-
15
EN
BEKA 2016 All rights reserved!
