BAL_2152_EP1_Central grease lubrication pump_0816_EN EDV-Nr. 1090200430
12. Adjustment of the control units:
12.1. Adjustment of the parameters:
The cycle time and lubrication time, the number of strokes and the number of revolutions can be
set by means of graduating switches in the inspection window of the control unit.
For the adjustment, remove the red frame at the pump‘s motor housing, using a flat screwdriver,
loosen the four Philips screws and remove the transparent protection cover.
The cycle time and lubrication time can be adjusted with a flat screwdriver.
If the cover plate is not replaced properly, water may enter the control unit
and damage it. Your guarantee expires in this case.
Graduating switch for setting the lubricating time
Graduating switch for setting the cycle time
System diagnosis port
Attention!
31
EN
BEKA 2016 All rights reserved!
