BAL_2152_EP1_Central grease lubrication pump_0816_EN EDV-Nr. 1090200430
19. Spare parts list:
Pos. Qty. Designation Item number
1 1 Pump housing 21520010
2 1 Motor housing above FMZ00437-00
3 1 Direct current gear motor 12 V 00503100001169
3.1 1 Direct current gear motor 24 V 00503100000496
4 1 Hydraulic form grease nippleA1 G1/4” 097141201211
5 1 Cap for hydraulic form grease nipple 1004010021
6 3 Cylinder screw with internal hexagon M6x25 090091204021
7 1 O-ring 135x3.5 for 1.9 kg reservoir 09037710210141
7.1 1 O-ring 135x3 for 2.5 to 8 kg reservoir 09037710152141
8 1 Eccentric unit 21520020
9 1 Perforated base plate 21520040
10 2 Cylinder screw with internal hexagon M4x12 090091200321
11 2 Spring ring B4 090012800411
12 0-3 Cu-sealing ring 27x20x1.5 090760300811
13 0-3 Pump element PE-60 without DBV incl. sealing ring 2152990670003
13.1 0-3 Pump element PE-120 without DBV incl. sealing ring 2152990610103
13.2 0-3 Pump element PE-170 without DBV incl. sealing ring 2152990690100
14 0-3 Pressure relief valve for PE-60, PE-120 a. PE-170 21520060
15 0-3 Pressure relief valve right for PE-60 to PE-170 21520076
with lubrication nipple without connecting piece
15.1 0-3 Pressure relief valve left for PE-60 to PE-170 21520068
with lubrication nipple without connecting piece
16 0-3 Pressure relief valve for PE-60 to PE-170 215299115
with micro switch for BEKA-troniX1 and EP-tronic
17 0-3 Pressure relief valve for PE-60 to PE-170 215299100
with micro switch without plug M12x1
18 0-3 Pump element PE-120 V without pressure relief 2152990630014
valve incl. sealing ring
19 0-3 Pressure relief valve for PE-120 V 21520063
20 0-3 Pressure relief valve for PE-120 V with micro switch 215299116
for BEKA-troniX1 and EP-tronic
21 0-3 Pressure relief valve for PE-120 V with micro switch 2152990610028
without plug
22 0-3 Screw plug M20x1.5 090090800850
23 1 Motor housing below with cable, 10 m 21520103
24 1 Motor housing below with bayonet connector 21520108
without connecting cable
25 1 Sealing for bayonet connector 08100192
26 1 4-pole bayonet connector without cable 1000913356
27 1 Motor housing below with integrated control unit see
BEKA-troniX1, EP-tronic, EP-tronic T1 or EP-T2 ordering key
27.1 1 Motor housing below with integrated PSU 21520113
115 VAC to 24 V DC
27.2 1 Motor housing below with integrated PSU 21520114
230 VAC to 24 V DC
28 1 Sealing for inspection window at motor housing below080100116
29 1 Inspection window for motor housing below FMZ00439-00
30 4 Slotted countersunk head screw M3x8 for 09i07046101121
inspection window
38
