BAL_2152_EP1_Central grease lubrication pump_0816_EN EDV-Nr. 1090200430
Pos. Qty. Designation Item number
31 1 Frame for inspection window, red FMZ00442-000 001
32 1 7-pole bayonet connector for integrated control units 1000912932
33 1 100091211
7-pole Hirschmann connector for FKGGM-EP with PSU
1.9 kg lubricant reservoir:
34 1 Agitator blade f. 1.9 kg reservoir w. fastening material 21520053
35 1 Transparent reservoir 1.9 kg FMZ00460-00
36 1 Filling level sticker for 1.9 kg reservoir BEKA-MAX 0490030103
3 4 M4x127 Socket head cap screw , Tuflok coated 0900912003232
2.5 kg lubricant reservoir (outside dia. 150 mm):
38 1 Agitator blade f. 2.5 kg reservoir w. fastening material 21520050
39 4 Connecting rod for 2.5 kg lubricant reservoir 0802000345
40 1 Transparent reservoir 2.5 kg (outside dia. 150 mm) F0396/03-00
41 1 Filling level sticker f. 2.5 kg reservoir, model for grease,0490030049
with BEKA-MAX-Logo
42 1 Head nut M4, DIN 986 090098600113
43 1 Ventilation tube f. 2.5 kg reservoir FMZ00486-00
44 1 O-ring f. reservoir cover f. 2.5 kg reservoirs09037710130,07x1,78 057141
45 1 Reservoir cover 2,5 kg incl. O-ring, 21520380
head nut and ventilation pipe
46 1 Reservoir cover 2,5 kg with filling cover, incl. 21520381
O-ring, head nut and ventilation pipe
47 1 Cable with plug-type connection M12x1 angled with 1000912997
free end, 5 m, for connection of level monitoring
48 1 Reservoir cover for 2,5 kg with level monitoring see
min. with plug-type connect. M12x1, standard vers., order key
with or without cable, incl. O-ring, cap nut and ventilation pipe
48.1 1 Reservoir cap 2,5 kg with level monitoring see
min. with plug connection M12x1, low temp. version order key
with or without connection cable, incl. O-ring, head nut a. ventilation pipe
49 1 Cable with plug-in connector M12x1 angular on both 1000912998
sides, length 0,6 m, for connection of the level monitoring
to the integrated control units BEKA-troniX1 and EP-tronic
50 1 Reservoir cap 2,5 kg with filling cover with see
level monitoring order key
min. w. cubic plug,10-60 V DC
with or without connection , incl. O-ring, head nut a. ventilation pipe
50.1 1 Reservoir cover 2,5 kg with filling cover., with grease see
level monitoring order key
min. , 90-250 VAC, withw. cubic plug
NO, NC contact, with or without connection piece
incl. O-ring, head nut a. ventilation pipe
51 1 Screw cap 04500020
4 resp. 4,2 kg lubricant reservoir (outside dia. 180 mm):
5 1 Intermediate flange 4 resp. 4.2 kg (model for grease) FMZ00426-002
5 1 O-ring 165x3 (model for grease) 090377100621413
5 4 Countersunk screw M4x35 (model for grease) 0907991001114
5 4 Connecting rod for 4 kg lubricant reservoir 08020003495
5 1 Agitator blade for 4 kg reservoir incl. fastening material215200516
57 1 Transparent reservoir 4 resp. 4.2 kg and 8 kg, 2 parts F0395/17-00
(outside Ø 180 mm)
39
EN
BEKA 2016 All rights reserved!
