Device description
4.3 Measuring ranges
5290 / 06/2023 en BENNING PV 1-1+ 23
4.3.2 Voltage ranges
Open-circuit voltage V
OC
of the PVmodule or PVstring
Measuring range Resolution Measuring accuracy
5.0…1 000V 0.1V ±(0.5%+ 2digits)
Table10: Measuring range for measuring the open-circuit voltage V
OC
of the PVmodule or PVstring
Voltage via 4mm test sockets
Measuring range Resolution Measuring accuracy
(AC: 50… 60Hz, DC)
30…440V‑AC/ V‑DC 1V ±(5%+ 2digits)
Table11: Measuring range for measuring the voltage via the 4mm test sockets
4.3.3 Current ranges
Short-circuit current I
SC
of the PVmodule or PVstring
Measuring range Resolution Measuring accuracy
0.5… 14.99A 0.01A ±(1%+ 2digits)
Table12: Measuring range for measuring the short-circuit current I
SC
of the PVmodule or PVstring
Current via current clamp adapter BENNINGCC3 (optional)
Measuring range Resolution Measuring accuracy
(AC: 50… 60Hz, DC)
0.1…40A‑AC/ A‑DC 0.1A ±(5%+ 2digits)
Table13: Measuring range for measuring the current using the current clamp adapter BENNINGCC3 (op-
tional)
