Technical data
5290 / 06/2023 enBENNING PV 1-1+42
7 Technical data
Protection class II (double or reinforced insulation)
Contamination level 2
Protection category
(DINVDE0470-1, IEC/ EN60529)
IP40
1st digit: 4= protection against access to
dangerous parts and protection against solid
impurities (diameter >1.0mm)
2nd digit: 0= no protection against water
Overvoltage category • PV test sockets: CATI 1 000V to earth
• 4mm test sockets: CATI 1 000V, CATIII
300V to earth
Housing dimensions
(lengthx widthx height)
270mmx 115mmx 80mm
Weight (batteries included) 1.2kg
Battery life (alkaline batteries) Approx. 3 000 automatic measurements at an
insulating voltage of 500V
Electromagnetic compatibility (EMC) IEC/ DINEN61326
4mm safety measuring lines
Standard IEC/ DINEN61010‑031(VDE0411‑031)
Overvoltage category
(only applies to the safety measuring lines,
additionally observe the limitations of the
device)
• With attachable protective cap:
– CATIII 1 000V to earth
– CATIV 600V to earth
• Without attachable protective cap:
– CATII 1 000V to earth
Protection class II (double or reinforced insulation)
Contamination level 2
Max. rated current 10A
Length 1.2m
PV safety measuring lines
Overvoltage category
(only applies to the safety measuring lines,
additionally observe the limitations of the
device)
• CATI 1 000V to earth
Protection class II (double or reinforced insulation)
Contamination level 2
Max. rated current 15A
Length 0.5m
Operation
Operating duration Short-term use (no continuous operation)
Max. barometric altitude 2 000m
Operating temperature 0…40°C (do not permanently expose the
device to sunlight)
Max. relative air humidity 80%RH (0…30°C),
75%RH (31…40°C)
Operating conditions To be used inside or outside buildings, both in
dry environments
