Connection22
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
• In the connections shown below, some cables may not be included with the projector (see
"Shipping contents" on page 8). They are commercially available from electronics stores.
• The connection illustrations below are for reference only. The rear connecting jacks
available on the projector vary with each projector model.
HDMI connection
3. HDMI cable 7. Audio cable
3
7
Notebook or desktop
computer
A/V device
Speakers
BenQ W1300.book Page 22 Thursday, August 29, 2013 2:07 PM
