Operation30
Fine-tuning the image size and clarity
1. Adjust the projected image to the size that
you need using the ZOOM ring.
2. Then sharpen the image by rotating the
FOCUS ring.
Correcting keystone
Keystoning refers to the situation where the projected image is noticeably wider at either
the top or bottom. It occurs when the projector is not perpendicular to the screen.
To correct this, besides adjusting the height of the projector, you can use Keystone
manually correct it following one of these steps.
1. Press MENU/EXIT and then press /
until the
Display menu is highlighted.
2. Press to highlight Keystone and press
MODE/ENTER. The Keystone
correction page displays.
3. Press to correct keystoning at the
top of the image or press to correct
keystoning at the bottom of the image.
ZOOM
FOCUS
ZOOM
FOCUS
Press /.Press /.
6
KEYSTONE
Back
MENU
