7 - PARAMETER DESCRIPTION
Vin2 Filter I/O 30
I/O: Vin2 Filter
30 15ms
LCD Display
Range 1 to 100ms (Default 15ms)
Description This parameter sets the low-pass lter time for the analog input signal being received at terminals Vin2.
Longer lter times better reduce noise disturbances but will also slow the signal response time.
See also I/O 27, 28, 29, 31
Set K-factor I/O 31
I/O: Set k-Factor
31 0.0%
LCD Display
Range 0 to 100% (Default 0.0%)
Description When parameters DRV 05 (Freq Mode 1) or DRV 07 (Freq Mode 2) are set to “Vin1 + k * Vin2”, this
parameter sets the value of k, which is the scale factor by which reference 2 is multiplied before being
added to reference 1.
See also I/O 27, 28, 29, 30
Vmet – Imet I/O 32, 33
I/O: Vmet Cong
32 Out Freq
I/O: Imet Cong
33 Out Torque
LCD Display
Parameter Value Function
Not Assign
Output is not used
Out Freq (I/O 32 Default)
Percentage of nominal motor frequency supplied to the motor. (see AFN01)
Out Torque (I/O 33 Default)
Estimated percentage of torque
Out Volt
Percentage of full voltage supplied to the motor (see FUN01)
Out Power
Percentage of calculated power (max is 250% of drive rating)
Ref Freq
Percentage of maximum frequency commanded (see AFN04)
PID Fback
Percentage of full scaled PID output (0-100%)
Bus Voltage
Percentage of nominal DC bus level
Output Curr
Percentage of output current
Range
Description Analog voltage output and Analog current output congure. These parameters congure what variable
governs the analog outputs Vmet and Imet. Vmet is a 0 to 10VDC output, Imet is a 0 to 20mA output.
See also I/O 34, 35, 36, 40, 41
