BENSHAW RSi S4 Series User Manual

11
ENVIRONMENTAL
2 - TECHNICAL SPECIFICATIONS
Ratings for 600VAC
2.2 Environmental Specifications
Model number
Frame
Size
Normal Duty Input current (A) Output current (A) Heavy Duty Input current (A) Output current (A)
HP kW - 600VAC - 600VAC HP kW - 600VAC - 600VAC
RSi001S46W
1
1 0.75 - 2.0 - 1.7 0.5 0.37 - 1.2 - 0.9
RSi002S46W
1
2 1.5 - 3.6 - 2.7 1 0.75 - 2.0 - 1.7
RSi003S46W
1
3 2.2 - 5.0 - 3.9 2 1.5 - 3.6 - 2.7
RSi005S46W
1
5 4 - 7.6 - 6.1 3 2.2 - 5.0 - 3.9
RSi007S46W
1
7.5 5.5 - 10.4 - 9.0 5 4 - 7.6 - 6.1
RSi010S46W
1
10 7.5 - 14.1 - 11.0 7.5 5.5 - 10.4 - 9.0
RSi015S46W
2
15 11 - 23 - 17 10 7.5 - 14.1 - 11
RSi020S46W
2
20 15 - 31 - 22 15 11 - 23 - 17
RSi025S46W
2
25 18 - 37 - 27 20 15 - 31 - 22
RSi030S46W
2
30 22 - 39.5 - 32 25 18 - 37 - 27
RSi040S46W
3
40 30 - 49 - 41 30 22 - 39.5 - 32
RSi050S46W
3
50 37 - 58 - 52 40 30 - 49 - 41
RSi060S46W
4
60 45 - 68 - 62 50 37 - 58 - 52
RSi075S46W
4
75 55 - 82 - 77 60 45 - 68 - 62
RSi100S46W
4
100 75 - 107 - 99 75 55 - 82 - 77
RSi125S46D
5
125 90 - 125 - 125 100 75 - 99 - 99
RSi150S46D
5
150 110 - 144 - 144 125 90 - 125 - 125
RSi200S46D
5
200 149 - 192 - 192 150 110 - 144 - 144
Operating temperature
For 003S42W,005S42W,030S42W,030S44W,005S46W,030S46W models:
–10°C to +35°C (14°F to 95°F)
–10°C to +40°C (14°F to 104°F) - All other models
Storage temperature –20°C to +65°C (-4°F to 149°F)
Humidity 0% to 95% non-condensing
Altitude 1000m (3300ft) without derating
Maximum vibration per EN50178 (1g @ 57-150 Hz)
Acoustic noise 80 dBa sound power at 1m (3ft), max
Cooling
1 to 5 HP models: Natural convection
7.5 to 200 HP models: Forced air
Note: 600Vac 5 HP model has a fan.
