6 - S4 PARAMETER GROUPS
6.1.2 FUN Group
Code
Parameter
Name
Default Range (Options) Modbus
View
Only
Page
DRV 19 Stator Freq Read-Only 0.0 to Max Hz 40019 X 81
DRV 20 Load Torque Read-Only -250.0 to 250.0 % 40020 X 81
DRV 21 SW Manual Read-Only 40021 X 81
DRV 22 Drive Model Read-Only RSi001S4-1
RSi001S4-2 to RSi030S4-2
RSi001S4-4 to RSi200S4-4
RSi001S4-6 to RSi200S4-6
40022 X 82
Code
Parameter
Name
Default Range (Options) Modbus
View
Only
Page
FUN 00 Jump Code
FUN 01 Nom Mtr Volt Model Dependant Model Dependant 40101 82
FUN 02 Torque Curve 1 = Linear Fxd 0 = Linear Auto
1 = Linear Fxd
2 = Pump Fxd
3 = Fan Fxd
4 = Linear 2pc
5 = Vector
40102 83
FUN 03 Start Mode 0 = LS Lockout 0 = LS Lockout
1 = AutoStart
2 = LSL w/Fly
3 = Auto w/Fly
40103 83
FUN 04 EMOP Cong 0 = TS no Mem 0 = TS no Mem
1 = TS Mem
2 = T/K Mem
3 = TS Stp
4 = TS Mem Stp
5 = T/K Mem Stp
40104 84
FUN 05 DB Cong 1 = DB Internal 0 = No Dyn Brk
1 = DB Internal
2 = DB External
3 = Int-ARCTIC
40105 85
FUN 06 DC Inj Cfg 0 = DC at Stop 0 = DC at Stop
1 = DC at Start
2 = DC at Both
3 = DC on Freq
40106 86
FUN 07 DC Inj Freq 0.0Hz 0.0 to 20.0 Hz 40107 86
FUN 08 DC Inj Time 0.2 sec 0.0 to 60.0 s 40108 87
FUN 09 DC Inj Lvl 50.00% 0.0 to 100.0 % 40109 87
FUN 10 Curr Lim Sel 0 = Fixed Lvls 0 = Fixed Lvls
1 = Vin2
2 = Cin
3 = Vin2 Motor
4 = Cin Motor
5 = Vin2 F-Mtr
6 = Cin F-Motor
40110 87
FUN 11 Curr Lim M/F 120% 5 to 200 % 40111 88
