LCDDisplays
Figure 26: Drive is in rem mode
FWD At Spd T/K
60.0Hz +0%
FWD At Spd LOC
60.0Hz +0%
5 - KEYPAD OPERATION AND PROGRAMMING
5.6 LCD Displays
5.6.1 Control (loc/rem) button
The characters in the top right hand corner of the operate screen show the source of control for the drive:
Modes (loc/rem) key can be set as:
Figure 25: Drive is in loc mode
In gure 25 the drive is in loc mode which means the Start/Stop & Speed reference control paths come
from the keypad.
In gure 26 the T/K is an example of one of the control sources during remote mode. The chart above
shows all the paths that may be set. The rst letter (T in example) is for parameter DRV 04 - Drive Mode
1 and will set the control (run command) source. The second letter (K in example) is for DRV 05 - Freq
Mode 1 and will set the reference (speed) source.
z NOTE: If the drive is running and the “loc/rem” button is pressed, the drive will stop if the new control
source does not have a run command.
z NOTE: To disable this button go to page 117 AFN 21 - loc/rem button.
Display Value for Remote Mode Meaning
LOC
Local control via the keypad
K/K
Keypad control / Keypad reference
K/T
Keypad control / Terminal reference
T/K
Terminal control / Keypad reference
T/T
Terminal control / Terminal reference
S/K
Serial control / Keypad reference
S/T
Serial control / Terminal reference
S/S
Serial control / Serial reference
T/S
Terminal control / Serial reference
K/S
Keypad control / Serial reference
