140
FLT: Last Trip 1*
01 MOL
FLT:Last Trip 2*
02 MOL
FLT: Last Trip 5*
05 MOL
FLT: Last Trip 3*
03 MOL
FLT: Last Trip 4*
04 MOL
7 - PARAMETER DESCRIPTION
7.3 FLT Group
The FLT Group shows the last ve faults:
The descriptions of all possible faults can be found in Chapter 8 on page 146: S4 Fault Codes.
Below is a list of values that show what the drives conditions were in when the fault occurred. Press
[ENTER] on the keypad when the fault screen is being displayed (above displays) and scroll through the
data.
The following information is available:
FLT..A- Output Frequency FLT..J- Adv Flt Code
FLT..B- Drive Load FLT..K- Ctl Brd Temp
FLT..C- Drive Status FLT..L- Out Power
FLT..D- Drive Warn FLT..M- Power Time
FLT..E- Output Volts FLT..N- Inputs
FLT..F- Output Curr
FLT..G- Drive Temp
FLT..H- Run Time
FLT..I- Bus Voltage
z NOTE: Press [MENU] to go back to previous screen.
