168
C - S4 PARAMETERS
Code Parameter Name Default Range (Options) Modbus
View
Only
Page User Setting
I/O 39 Vin2 Status Read-Only 0.00 to 100.00% 40339 X 106
I/O 40 Vmet Status Read-Only 0.00 to 100.00% 40340 X 107
I/O 41 Imet Status Read-Only 0.00 to 100.00% 40341 X 107
I/O 42 DOP Scaling 0 = 6FS 0=”6FS” 1=”48FS” 40342
107
I/O 43 Speed Ratio 100.00% 0.0-200.0% 40343
108
I/O 44 Inputs Read-Only Bit 0 -> FWD DI
Bit 1 -> REV DI
Bit 2 -> R/J DI
Bit 3 -> DI1
Bit 4 -> DI2
Bit 5 -> DI3
Bit 6 -> DI4
Bit 7 -> DI5
Bit 8 -> MOL DI
Bit 9 -> EN DI
40344 X 108
I/O 45 Outputs Read-Only Bit 0 -> R1 Relay
Bit 1 -> R2 Relay
Bit 2 -> DO1 Output
Bit 3 -> DO2 Output
40345 X 108
I/O 46 Com Parity 0 = RTU N81 0 = RTU N81
1 = RTU N82
2 = RTU E81
3 = RTU O81
40346
109
I/O 47 Com Drop # 1 1-247 40347
109
I/O 48 Com Baudrate 1 = 9600 0 = 4800
1 = 9600
2 = 19200
3 = 38400
4 = 57600
40348
109
I/O 49 Com Timeout 0.0 sec 0.0 to 60.0 sec 40349
110
I/O 50 Infared Baud Rate 1 = 9600 1 = 9600
2 = 19200
3 = 38400
4 = 57600
40350
110
11.3.4 AFN Group
Code Parameter Name Default Range (Options) Modbus
View
Only
Page User Setting
AFN 00 Jump Code
AFN 01 Nom Mtr Freq Model Dependant 25.0 to 400.0 Hz 40501
111
AFN 02 Nom Mtr RPM 1750 rpm 1 to 24000 rpm 40502
111
AFN 03 Minimum Freq 0.0 Hz 0.0 to 400.0Hz 40503
111
AFN 04 Maximum Freq 60.0Hz Minimum Freq to
400.0Hz
0504
111
AFN 05 Carrier Freq 3.0kHz 1.0 to 16.0kHz 40505
112
AFN 06 Slip Comp 0=”No” 0 = No
1 = Yes
0506
112
AFN 07 V-Boost Conf 1.0% 0.0% to 50.0% 40507
112
AFN 08 Bst. Tpr Frq 60.0Hz 0.0Hz to
Maximum Freq
40508
113
AFN 09 Bst. Tpr Vlt 100.0% 0.0 to 100.0 % 40509
113
AFN 10 Motor RS Model Dependant 0.0 to 655.35 ohm 40510
AFN 11 Auto-Tune 0 = Not Active 0 = Not Active
1 = Motor RS
40511
114
