BENSHAW RSi S4 Series User Manual

171
C - S4 PARAMETERS
11.3.5 APP Group
Code Parameter Name Default Range (Options) Modbus Page User Setting
APP 00 Jump Code
133
APP 01 Seq Appl 0 = Disabled 0 = Disabled
1 = 1sec base
2 = .1sec base
3 = .01sec base
40701
APP 02 Seq Cntl 1 00000000000 Bit 0-2 -> Speed Sel
Bit 3 -> Accl Sel
Bit 4-6 -> Event Length
Bit 7-8 -> Dir Sel
Bit 9-10 -> Output Sel
40702
APP 03 Seq Cntl 2 00000000000 Bit 0-2 -> Speed Sel
Bit 3 -> Accl Sel
Bit 4-6 -> Event Length
Bit 7-8 -> Dir Sel
Bit 9-10 -> Output Sel
40703
APP 04 Seq Cntl 3 00000000000 Bit 0-2 -> Speed Sel
Bit 3 -> Accl Sel
Bit 4-6 -> Event Length
Bit 7-8 -> Dir Sel
Bit 9-10 -> Output Sel
40704
APP 05 Seq Cntl 4 00000000000 Bit 0-2 -> Speed Sel
Bit 3 -> Accl Sel
Bit 4-6 -> Event Length
Bit 7-8 -> Dir Sel
Bit 9-10 -> Output Sel
40705
APP 06 Seq Cntl 5 00000000000 Bit 0-2 -> Speed Sel
Bit 3 -> Accl Sel
Bit 4-6 -> Event Length
Bit 7-8 -> Dir Sel
Bit 9-10 -> Output Sel
40706
APP 07 Seq Cntl 6 00000000000 Bit 0-2 -> Speed Sel
Bit 3 -> Accl Sel
Bit 4-6 -> Event Length
Bit 7-8 -> Dir Sel
Bit 9-10 -> Output Sel
40707
APP 08 Seq Cntl 7 00000000000 Bit 0-2 -> Speed Sel
Bit 3 -> Accl Sel
Bit 4-6 -> Event Length
Bit 7-8 -> Dir Sel
Bit 9-10 -> Output Sel
40708
APP 09 Seq Cntl 8 00000000000 Bit 0-2 -> Speed Sel
Bit 3 -> Accl Sel
Bit 4-6 -> Event Length
Bit 7-8 -> Dir Sel
Bit 9-10 -> Output Sel
40709
APP 10
Seq Cntl 9
00000000000 Bit 0-2 -> Speed Sel
Bit 3 -> Accl Sel
Bit 4-6 -> Event Length
Bit 7-8 -> Dir Sel
Bit 9-10 -> Output Sel
40710
APP 11
Seq Count 1
0 0-65535 40711
APP 12
Seq Count 2
0 0-65535 40712
APP 13
Seq Count 3
0 0-65535 40713
APP 14
Seq Count 4
0 0-65535 40714
APP 15 Seq Count 5 0 0-65535 40715
APP 16 Seq Count 6 0 0-65535 40716
APP 17 Seq Count 7 0 0-65535 40717
APP 18 Seq Count 8 0 0-65535 40718
APP 19 Seq Count 9 0 0-65535 40719
