BENSHAW RSi S4 Series User Manual

170
C - S4 PARAMETERS
Code Parameter Name Default Range (Options) Modbus
View
Only
Page User Setting
AFN 38 PID Low Alm 0.00% 0.00 to 100.00 % 40538 125
AFN 39 PID Sleep 0 = Disabled
0 = Disabled
1 = PID FBk <
2 = PID FBk >
3 = PID Ref <
4 = PID Ref >
40539 125
AFN 40 Sleep Lvl 0.00% 0.00 to 100.00 % 40540 126
AFN 41 Wake-Up Lvl 0.00% 0.00 to 100.00 % 40541 126
AFN 42 Sleep Delay 0.0 sec 0.0 to 300.0 sec 40542 126
AFN 43 Wake-Up Dly 0.0 sec 0.0 to 300.0 sec 40543 127
AFN 44 PID Ref Read-Only 0.00 to 100.00 % 40544 127
AFN 45 PID FB Read-Only 0.00 to 100.00 % 40545 127
AFN 46 PID Error Read-Only 0.00 to 100.00 % 40546 127
AFN 47 PID Output Read-Only 0.00 to 100.00 % 40547 128
AFN 48 PID High Lim 100.00% 0.00 to 100.00 % 40548 128
AFN 49 PID Low Lim 0.00% 0.00 to 100.00 % 40549 128
AFN 50 PID Usr Unt 0 = No
0 = No
1 = Yes
40550 128
AFN 51 Software Rev Read-Only N/A 40551 X 129
AFN 52 Serial No 1 Read-Only N/A 40552 X 129
AFN 53 Serial No 2 Read-Only N/A 40553 X 129
AFN 54 Language 0 = English 0 = English 40554 129
AFN 55 Prog Number 0 Varies 40555 130
AFN 56 Par STO/RCL 0 = Select…
0 = Select…
1 = Factory Rst
2 = Store Parm
3 = Load Param
4 = Swap Param
40556 130
AFN 57 Power Fail Cfg CTS No Msg
0 = CTS No Msg
1 = Coast Stop
2 = Ramp Down
3 = Quick Ramp
4 = Controlled
5 = ContrNoMsg
40557 131
AFN 58 Ride-Thru En w/ LVT
0 = Disabled
1 = w/ LVT
2 = w/o LVT
3 = No UV Fault
40558 131
AFN 59 Cutoff Freq 0.0 Hz 0.0 to 5.0 Hz 40559 132
AFN 60 Stab. Gain 0 0 to 10 40560 132
AFN 61 Stab. Rate 5 1 to 1000 40561 132
