BENSHAW RSi S4 Series User Manual

129
PID Output AFN 47
PID High Lim AFN 48
AFN: PID Output
47 +0.00%
AFN: PID High Lim
48 100.00%
7 - PARAMETER DESCRIPTION
LCD Display
Range 0.00 to 100.00% (view only)
Description This parameter shows the value of the PID output, expressed as a percentage of maximum frequency.
LCD Display
Range 0.00 to 100.00% (Default 100.00%)
Description This parameter sets the high limit of PID output. The range is 0.00 to 100.00% of the maximum frequency.
PID Low Lim AFN 49
PIDUserUnt AFN50
AFN: PID Low Lim
49 0.00%
AFN: PID Usr Unts
50 No
LCD Display
Range 0.00 to 100.00% (Default 0.00%)
Description This parameter sets the low limit of PID output. The range is 0.00 to 100.00% of the maximum frequency.
LCD Display
Range Yes
No (Default)
Description This parameter sets whether the drive will use units when in PID control. If set to Yes, the user units can
be set in FUN 42 (Units). The actual values of the feedback signal and reference will then be displayed in
AFN 44 - PID Ref and AFN 45 - PID FB.
