128
Wake-Up Dly AFN 43
PID Ref AFN 44
PID FB AFN 45
AFN: Wake-Up Dly
43 0.0sec
AFN: PID Ref
44 0.00%
AFN: PID FB
45 0.00%
7 - PARAMETER DESCRIPTION
LCD Display
Range 0.00 to 300.0 seconds (Default 0.0s)
Description This parameter sets the wake-up delay time. When the PID signal (AFN 39 selection) becomes greater
than the Wake Up Level (AFN 41), the drive waits for this Wake-Up Delay time to expire before resuming
output.
See also AFN 39 - PID Sleep
LCD Display
Range 0.00 to 100.00% (view only)
Description This parameter shows the set point for the PID control loop. The set point is expressed as a percentage of
the maximum frequency. The value shown in this parameter can be used to determine whether the control
path of the drive is congured correctly.
LCD Display
Range 0.00 to 100.00% (view only)
Description This parameter shows the feedback signal as a percentage of the maximum frequency. This parameter
may be used to determine if the analog input is congured correctly with respect to span and offset. It can
also be sent to either the Imet or Vmet analog output terminal if the analog output is congured to the PID
feedback signal.
PID Error AFN 46
AFN: PID Error
46 +0.00%
LCD Display
Range 0.00 to 100.00% (view only)
Description This parameter shows the value of the error between AFN 45 - PID FB and AFN 44 - PID Ref.
