127
Wake-Up Lvl AFN 41
Sleep Delay AFN 42
AFN: Wake-Up Lvl
41 0.00%
AFN: Sleep Delay
42 0.0sec
7 - PARAMETER DESCRIPTION
Sleep Lvl AFN 40
AFN: Sleep Lvl
40 0.00%
LCD Display
Range 0.00 to 100.00% (Default 0.00%)
Description This parameter sets the sleep level as a percent of full scale. When the PID signal (AFN 39 selection) is
within this percentage, the drive stops. The PID function remains active. When the PID signal becomes
greater than the Wake Up Level, (AFN 41) the drive will begin to run.
See also AFN 39 - PID Sleep
LCD Display
Range 0.00 to 100.00% (Default 0.00%)
Description This parameter sets the wake-up level as a percentage of full scale below the sleep level. When the PID
signal (AFN 39 selection) becomes greater than this, the drive will begin to run.
Example If the sleep level is set to 75%, and the wake up level at 10% the drive will stop at 75% and wake at 65%.
See also AFN 39 - PID Sleep
AFN 40 - Sleep Lvl
LCD Display
Range 0.00 to 300.0 seconds (Default 0.0s)
Description This parameter sets the sleep delay. When the PID signal (AFN 39 selection) is within the percentage set
by AFN 40 - Sleep Lvl, the drive waits for the Sleep Delay time to expire before stopping.
See also AFN 39 - PID Sleep
