INTERPRETING MODEL NUMBERS
007 RSi S4 2 W
Benshaw RediStart Inverter
Standard Duty Motor HP rating:
001 – 200 HP
Series name of inverter
Input voltage
2 = 220V – 240V class
4 = 440V – 480V class
6 = 575V – 600V class
1 = 110V – 120V class
Enclosure
W = NEMA 4X
D = NEMA 12
C = Chassis
1 - INTRODUCTION
1.2 Interpreting Model Numbers
Model Numbers The model number of the RSi S4 drive appears on the shipping carton label and
on the technical data label afxed to the model. Read the technical data label
afxed to the drive and ensure that the correct horsepower and input voltage for
the application has been purchased. The numbering system for a Benshaw
inverter is shown below.
Figure 1: RSi S4 Drive Model Numbers
Name Plate Example
