BENSHAW RSi S4 Series User Manual

163
C - S4 PARAMETERS
11.3 APPENDIX C: S4 Parameter Groups
11.3.1 DRV Group
Code Parameter
Name
Default Range (Options) Modbus View
Only
Page User Setting
DRV 01 Nom Mtr Amps Nominal for Drive Model Dependant 40001 75
DRV 02 Accel Time 1 5.0 sec 0.1 - 3200.0 sec 40002 76
DRV 03 Decel Time 1 5.0 sec 0.1 - 3200.0 sec 40003 76
DRV 04 Drive Mode 1 0 = Keypad 0 = Keypad
1 = Terminal 1
2 = Terminal 2
3 = Serial
40004 77
DRV 05 Freq Mode 1 0 = Keypad 0 = Keypad
1 = Vin1
2 = Cin”
3 = Vin2”
4 = Vin1 6FS”
5 = Vin1 48FS”
6 = Vin1+Cin”
7 = Vin1+Vin2”
8 = Vin1-Cin”
9 = Vin1-Vin2”
10 = Vin1+k*Cin”
11 = Vin1+k*Vin2”
12 = Max Input”
13 = EMOP”
14 = Serial
40005 78
DRV 06 Drive Mode 2 2 = Terminal 2 0 = Keypad
1 = Terminal 1
2 = Terminal 2
3 = Serial”
40006 78
DRV 07 Freq Mode 2 1 = Vin1 0 = Keypad
1 = Vin1
2 = Cin
3 = Vin2
4 = Vin1 6FS
5 = Vin1 48FS
6 = Vin1+Cin
7 = Vin1+Vin2
8 = Vin1-Cin
9 = Vin1-Vin2
10 = Vin1+k*Cin
11 = Vin1+k*Vin2
12 = Max Input
13 = EMOP
14 = Serial
40007 79
DRV 08 Output Curr. Read-Only 0.0 to 999.9 A 40008 X 79
DRV 09 Output Volts Read-Only 0 to 1000 V 40009 X 79
DRV 10 Output Power Read-Only 0.0 to 655.35 kW 40010 X 79
DRV 11 MWh Meter Read-Only 0 to 32767 MWh 40011 X 79
DRV 12 kWh Meter Read-Only 0.0 to 999.9 kWh 40012 X 80
DRV 13 Run Time Read-Only 0.0 to 6553.5 h 40013 X 80
DRV 14 Power Time Read-Only 0 to 65535 h 40014 X 80
DRV 15 Output Freq Read-Only 0.0-400.0 Hz 40015 X 80
DRV 16 Drive Load Read-Only -250.0 to 250.0 % 40016 X 80
DRV 17 Drive Temp Read-Only -20.0 to 125.0
Celcius
40017 X 81
DRV 18 Bus Voltage Read-Only 0 to 1000 Vdc 40018 X 81
