Drive Temp DRV 17
DCBusVoltage DRV 18
Stator Freq DRV 19
DRV: Drive Temp
17 +31.4
o
C
DRV: Bus Voltage
18 331 Vdc
DRV: Stator Freq
19 0.0 Hz
7 - PARAMETER DESCRIPTION
LCD Display
Description The Drive Temp parameter shows the actual temperature of the drive’s heatsink.
LCD Display
Description The DC Bus Voltage displays the voltage on the DC bus.
LCD Display
Description Stator Frequency displays the frequency the drive is applying to the motor stator.
Load Torque DRV 20
SW Manual DRV 21
DRV: Load Torque
20 +0.0%
DRV: SW Manual
21 890035-01-02
LCD Display
Description The Load Torque parameter displays the load torque of the drive.
LCD Display
Description This is the document number for the applicable S4 User Guide.
z NOTE: This is a view only parameter, it cannot be changed.
To Next Page
