59
UPGRADING FIRMWARE BY REFLASHING
QUICK START
5 - KEYPAD OPERATION AND PROGRAMMING
5.8 Upgrading Firmware by Reflashing
The rmware of the RSi S4 Sensorless Vector Drive can by upgraded by a process called “reashing.” This
allows the latest features to be implemented in existing hardware.
The procedure for upgrading rmware by reashing is as follows:
Stop the drive, and clear any faults •
Press [stop/reset] and [menu] buttons simultaneously •
Connect the reash cable to the RJ45 jack on the TSP board •
Connect the other end of the cable to the PC •
Open the reash software on the PC •
Open the new code le •
Click the reash button •
When reashing is complete press [stop/reset] button and load the new factory defaults. See parameter •
AFN 56 - Par STO/RCL. •
z NOTE: See page 158 for more information on the RJ45 jack.
5.9 Quick Start
These QuickStart instructions are for those applications where:
The user wants to get the RSi S4 Series inverter started quickly.•
The factory default values are suitable for the user application.•
The factory default values are shown in Section 6 - Parameter Groups of this manual. The factory
settings are for the drive to run a typical NEMA B induction motor to a maximum speed of 60.00Hz with
acceleration and deceleration times of 5s. The jog frequency is set for 5.0Hz. It is recommended the user
become familiar with all parameters and features of the inverter before applying AC power when a more
advanced setup is required.
1. Apply power to the VFD.
2. Verify power up. The display should read as follows:
Stopped LOC
0.0Hz +0%
FUN: Torque Curve
02 Linear Fxd
3. Set FUN 02 (Torque Curve) to the setting that best describes your application.
z NOTE: If you are uncertain of the application’s load characteristics, leave the FUN 02 -Torque Curve
parameter at it’s default value: Linear Fxd.
To Next Page
