C - S4 PARAMETERS
11.3.2 FUN Group
Code
Parameter
Name
Default Range (Options) Modbus
View
Only
Page User Setting
DRV 19 Stator Freq Read-Only 0.0 Hz 40019 X 81
DRV 20 Load Torque Read-Only -250.0 to 250.0 % 40020 X 81
DRV 21 SW Manual Read-Only 40021 X 81
DRV 22 Drive Model Read-Only RSi001S4-1
RSi001S4-2 to RSi030S4-2
RSi001S4-4 to RSi200S4-4
RSi001S4-6 to RSi200S4-6
40022 X 82
Code
Parameter
Name
Default Range (Options) Modbus
View
Only
Page User Setting
FUN 00 Jump Code
FUN 01 Nom Mtr Volt Model Dependant Model Dependant 40101 82
FUN 02 Torque Curve 1 = Linear Fxd 0 = Linear Auto
1 = Linear Fxd
2 = Pump Fxd
3 = Fan Fxd
4 = Linear 2pc
5 = Vector
40102 83
FUN 03 Start Mode 0 = LS Lockout 0 = LS Lockout
1 = AutoStart
2 = LSL w/Fly
3 = Auto w/Fly
40103 83
FUN 04 EMOP Cong 0 = TS no Mem 0 = TS no Mem
1 = TS Mem
2 = T/K Mem
3 = TS Stp
4 = TS Mem Stp
5 = T/K Mem Stp
40104 84
FUN 05 DB Cong 1 = DB Internal 0 = No Dyn Brk
1 = DB Internal
2 = DB External
3 = Int-ARCTIC
40105 85
FUN 06 DC Inj Cfg 0 = DC at Stop 0 = DC at Stop
1 = DC at Start
2 = DC at Both
3 = DC on Freq
40106 86
FUN 07 DC Inj Freq 0.0Hz 0.0 to 20.0 Hz 40107 86
FUN 08 DC Inj Time 0.2 sec 0.0 to 60.0 s 40108 87
FUN 09 DC Inj Lvl 50.00% 0.0 to 100.0 % 40109 87
FUN 10 Curr Lim Sel 0 = Fixed Lvls 0 = Fixed Lvls
1 = Vin2
2 = Cin
3 = Vin2 Motor
4 = Cin Motor
5 = Vin2 F-Mtr
6 = Cin F-Motor
40110 87
FUN 11 Curr Lim M/F 120% 5 to 200 % 40111 88
