89
Curr Lim M/F FUN 11
FUN: Curr Lim M/F
11 120%
7 - PARAMETER DESCRIPTION
LCD Display
Range 5 - 200% (Default 120%)
Description Current limit motoring/forward. This parameter sets the current limiting point when the motor is driving
the load in the Forward direction. The limit is expressed as a percentage of the normal duty rated current
of the drive
See also FUN 10 - Curr Limit on page 87 for more programming options.
Curr Lim M/R FUN 12
Curr Lim R/F FUN 13
FUN: Curr Lim R/F
13 80%
FUN: Curr Lim M/R
12 120%
LCD Display
Range 5 - 200% (Default 120%)
Description Current limit motoring/reverse. This parameter sets the current limiting point when the motor is driving
the load in the Reverse direction. The limit is expressed as a percentage of the nominal motor amps.
See also FUN 10 - Curr Limit on page 87 for more programming options.
LCD Display
Range 5 - 200% (Default 80%)
Description Current limit regenerating/forward. This parameter sets the current limiting point when the load drives the
motor (regenerative mode) in the Forward direction. The limit is expressed as a percentage of the nominal
motor amps.
Curr Lim R/R FUN 14
FUN: Curr Lim R/R
14 80%
LCD Display
Range 5 - 200% (Default 80%)
Description Current limit regenerating/reverse. This parameter sets the current limiting point when the load drives the
motor (regenerative mode) in the Reverse direction. The limit is expressed a percentage of the nominal
motor amps.
