BENSHAW RSi S4 Series User Manual

166
C - S4 PARAMETERS
11.3.3 I/O Group
Code Parameter Name Default
Range
(Options)
Modbus
View
Only Page
User Seting
I/O 00 Jump Code
I/O 01 Active Logic 1 = Active High
0 = Active Low
1 = Active High
40301 96
I/O 02 DI1 Cong 1 = Preset 1 0 = Not Assign
1 = Preset 1
2 = Preset 2
3 = Preset 3
4 = Coast Stop
5 = DC Inject
6 = DRV/Frq Set
7 = Alt Ramp
8 = Fault Reset
9 = EMOP+
10 = EMOP-
11 = PID Disable
12 = Cur Lim Dis
13 = SL Override
14 = FLY Dis
15 = CurLimIMax
16 = Jog Fwd
17 = Jog Rev
18 = NO MOL
19 = NC MOL
20 = Timer 1
21 = Timer 2
22 = Seq 1
23 = Seq 2
24 = Seq 3
25 = Seq Dwel
26 = Seq Advance
40302
97
I/O 03 DI2 Cong 2 = Preset 2 40303
I/O 04 DI3 Cong 3 = Preset 3 40304
I/O 05 DI4 Cong 6 = DRV/Frq Set 40305
I/O 06 DI5 Cong 8 = Fault Reset 40306
I/O 07 MOL Cong 18 = NO MOL 40307
I/O 08 DO1 Cong 4 = Drv Ready 0 = Not Assign
1 = Drive Run
2 = Running Fwd
3 = Running Rev
4 = Drv Ready
5 = At Speed
6 = Drv Fault
7 = Drv NotFlt
8 = Kpd in Ctl
9 = Drv in Rem
10 = Jogging
11 = Curr Lvl 1
12 = Curr Lvl 2
13 = Trq Lvl 1
14 = Trq Lvl 2
15 = Frq Lvl 1
16 = Frq Lvl 2
17 = Frq Lvl 3
18 = Current Lim
19 = Loss Ref
20 = SL in Ctrl
21 = SL Override
22 = Zero Speed
23 = Frq Low Th
24 = PID High
25 = PID Low
26 = Timer 1
27 = Timer 2
28 = SeqOut-00
29 = SeqOut-01
30 = SeqOut-10
31 = SeqOut-11
32 = ARCTIC Mode
40308 98
I/O 09 DO2 Cong 5 = At Speed 40309
I/O 10 R1 Cong 6 = Drv Fault 40310 98
I/O 11 R2 Cong 1 = Drive Run 40311
