BENSHAW RSi S4 Series User Manual

167
C - S4 PARAMETERS
Code Parameter Name Default Range (Options) Modbus
View
Only
Page User Setting
I/O 12 Jog Speed 5.0 Hz 0.0 - 400.0 Hz 40312 99
I/O 13 Preset Spd 1 5.0 Hz 0.0 - 400.0 Hz 40313 99
I/O 14 Preset Spd 2 10.0 Hz 0.0 - 400.0 Hz 40314
I/O 15 Preset Spd 3 20.0 Hz 0.0 - 400.0 Hz 40315
I/O 16 Preset Spd 4 30.0 Hz 0.0 - 400.0 Hz 40316
I/O 17 Preset Spd 5 40.0 Hz 0.0 - 400.0 Hz 40317
I/O 18 Preset Spd 6 50.0 Hz 0.0 - 400.0 Hz 40318
I/O 19 Vin1 Cong 0-10V 0 = 0-10V
1 = 0-10V Brk W
2 = 0-10V I
3 = 0-10V Bipol
4 = 0-5V
5 = 0-5V I
6 = 0-20mA 250
7 = 0-20mA 250I
8 = 4-20mA 250
9 = 4-20mA 250I
10 = PT 0-1kHz
11 = PT 0-10kHz
12 = PT 0-100kHz
40319 100
I/O 20 Vin1 Span 100.00% 10.0 to 200.0% 40320 100
I/O 21 Vin1 Offset 0 0.0 to 100.0% 40321 101
I/O 22 Vin1 Filter 15 ms 1 to 1000 ms 40322 101
I/O 23 Cin Cong 2 = 0-20mA 50 0 = 4-20mA 50
1 = 4-20mA 50I
2 = 0-20mA 50
3 = 0-20mA 50I
40323 101
I/O 24 Cin Span 100.00% 10.0 to 200.0% 40324 102
I/O 25 Cin Offset 0 0.0 to 100.0% 40325 102
I/O 26 Cin Filter 15 ms 1 to 1000 ms 40326 102
I/O 27 Vin2 Cong 0 = 0-10V 0 = 0-10V
1 = 0-10V Brk W
2 = 0-10V I
3 = 0-10V Bipol
4 = 0-5V
5 = 0-5V I
40327 103
I/O 28 Vin2 Span 100.00% 10.0 to 200.0% 40328 103
I/O 29 Vin2 Offset 0 0.0 to 100.0% 40329 103
I/O 30 Vin2 Filter 15 ms 1 to 1000 ms 40330 104
I/O 31 Set k-Factor 0.0% 0.0%-100.0% 40331 104
I/O 32 Vmet Cong 1 = Out Freq 0 = Not Assign
1 = Out Freq
2 = Out Torque
3 = Out Volt
4 = Out Power
5 = Ref Freq
6 = PID Fback
7 = Bus Voltage
8 = Output Curr
40332 104
I/O 33 Imet Cong 2 = Out Torque 40333
I/O 34 Vmet Span 100.0% 0.0 - 200.0% 40334 105
I/O 35 Imet Span 100.0% 0.0-200.0% 40335 105
I/O 36 Imet Offset 0.0% 0.0-90.0% 40336 105
I/O 37 Vin1 Status Read-Only 0.00 to 100.00% 40337 X 106
I/O 38 Cin Status Read-Only 0.00 to 100.00% 40338 X 106
