MultifunctionInputTerminalDI1-DI5&MOLCongurationI/O02-I/O07
I/O: DI1 Cong
02 Preset 1
I/O: DI2 Cong
03 Preset 2
I/O: DI3 Cong
04 Preset 3
I/O: DI4 Cong
05 DRV/Frq Set
I/O: DI5 Cong
06 Fault Reset
I/O: MOL Cong
07 NO MOL
7 - PARAMETER DESCRIPTION
LCD Display
Range
Description Digital Inputs and Motor Overload conguration. The multi-function input terminals can be dened for
many different applications.
z NOTE: The MOL Input is congured by factory default as a normally open external motor overload. It
can be used as an additional multi-function input by changing the value of parameter I/O 07.
See also I/O 44 (Inputs) on page 108
Displayed Name Function Parameter
Preset 1 (Default - I/O2 : DI1)
Preset Speed Input 1 I/O 13-18
Preset 2 (Default - I/O3 : DI2)
Preset Speed Input 2 I/O 13-18
Preset 3 (Default - I/O4 : DI3)
Preset Speed Input 3 I/O 13-18
Coast Stop
Drive will coast to stop. Will restart upon removal of input if run is active. AFN 20
DC Inject
Begin DC Injection braking FUN 06-09
DRV/Frq Set (Default - I/O5 : DI4)
Selects second DRV/Frq source. Used with local/remote switch. DRV 06, 07
Alt Ramp
Select alternative ramp AFN 24, AFN 25
Fault Reset (Default - I/O6 : DI5)
Remote fault reset
EMOP+
Increase speed of electronic motorized pot FUN 04
EMOP-
Decrease speed of electronic motorized pot FUN 04
PID Disable
Disables PID function AFN 31
Curr Lim Dis
Disables current limit mode FUN 10
SL Override
Removes control of serial link
FLY Dis
Disables “Catch-on-the-y” mode AFN 18
CurLimIMax
Sets current limit to maximum value FUN 10-18
Jog FWD
Jog in Forward I/O 12
Jog REV
Jog in Reverse I/O 12
NO MOL (Default - I/O7 : MOL)
Normally Open motor overload I/O 07
NC MOL
Normally Closed motor overload I/O 07
Timer 1
Timer 1 coil FUN 34
Timer 2
Timer 2 coil FUN 36
Seq 1
Activate sequencer 1 APP Group
Seq 2
Activate sequencer 2 APP Group
Seq 3
Activate sequencer 3 APP Group
Seq Dwell
Sequencer dwell mode (pause) APP Group
Seq Advance
Sequencer advance (skip) APP Group
Not Assign
Input has no function APP Group
