109
Speed Ratio I/O 43
I/O: Speed Ratio
43 100.0%
7 - PARAMETER DESCRIPTION
LCD Display
Range 0% to 200.0% of pulse train input at Vin1 (Default 100.0%)
Description This parameter congures the drive when using I/O 19 as a Pulse Train Input. The drive will follow the
Pulse Train at the percentage programmed.
See also DRV 05, 07 on page 78 & I/O 42 on page 107
Inputs I/O44
I/O: Inputs
44 01000000000
LCD Display
Range 00000000000 to 11111111111 (view only)
Description This eleven bit binary number indicates the status of the discrete inputs at the terminals. A one (1) indicates
the input is true and a zero (0) indicates it is false.
Example 01000000001
Drive enable (EN) input is active, FWD input is active.
Bit 10 9 8 7 6 5 4 3 2 1 0
N/A EN MOL DI5 DI4 DI3 DI2 DI1 JOG REV FWD
Outputs I/O45
I/O: Outputs
45 00000000100
LCD Display
Range 00000000000 to 00000001111 (view only)
Description This eleven bit binary number indicates the status of the discrete outputs as shown below. A one (1)
indicates the input is true and a zero (0) indicates it is false.
Example 00000000010 - R2 is active.
See also I/O 08 to I/O 11 starting on page 98.
Bit 10 9 8 7 6 5 4 3 2 1 0
N/A N/A N/A N/A N/A N/A N/A DO2 DO1 R2 R1
