Freq Mode 2 DRV 07
Output Current DRV 08
Output Voltage DRV 09
Output Power DRV 10
DRV: Freq Mode 2
07 Vin1
DRV: Output Curr
08 0.0A
DRV: Output Volts
09 0V
DRV: Out Power
10 +0.00 kW
7 - PARAMETER DESCRIPTION
LCD Display
Range Same as DRV 05 (Default Vin 1)
Description This parameter provides the user a second frequency source to be selected by a digital input. This is often
used with a local/remote selector switch. To use this function, one of the digital inputs must be set to
Drv/Frq Set. DRV 07 will be used to select the frequency source when this input is closed. Otherwise the
drive uses the frequency source in DRV 05.
LCD Display
Description The Output Current parameter displays the output current of the drive.
LCD Display
Description The Output Voltage parameter displays the output voltage of the drive.
LCD Display
Description This parameter displays the power being output in terms of drive rating. The measurement is calculated by
scaling the Load Torque by the ratio of Volt-Amps to Rated Volt-Amps and adjusted by Output Frequency.
MWh Meter DRV 11
DRV: MWh Meter
11 0 MWh
LCD Display
Description This display shows the power (MWh) consumed by the load.
To Next Page
