BENSHAW RSi S4 Series User Manual

169
C - S4 PARAMETERS
Code Parameter Name Default Range (Options) Modbus
View
Only
Page User Setting
AFN 12 Power Factor 80.0% 0.50 to 1.00 40512 114
AFN 13 Fstator Filt 8 ms 1 to 100 ms 40513 115
AFN 14 Start Field 0 = No 0 = No
1 = Yes
40514 115
AFN 15 Filter Slip 100 ms 10 to 1000 ms 40515 115
AFN 16 ID Percent Read-Only -300.0 - 300.0% 40516 X 116
AFN 17 IQ Percent Read-Only -300.0 - 300.0% 40517 X 116
AFN 18 Catch Mode 0 = Sweep Fwd 0 = Sweep Fwd
1 = Sweep Rev
2 = Sweep F/R
40518 116
AFN 19 Run Prevent 0 = Forward 0 = Allow F/R
1 = No Reverse
2 = No Forward
40519 117
AFN 20 Stop Key 0 = Coast 0 = Coast
1 = Ramp
2 = Disabled
40520 117
AFN 21 Loc/Rem Key 1 = Enabled 0 = Disabled
1 = Enabled
40521 117
AFN 22 TOL Select 2 = Std Ind 60s 0 = Std Ind Shp
1 = Std Ind 30s
2 = Std Ind 60s
3 = Std Ind 5mn
4 = In Duty Shp
5 = In Duty 30s
6 = In Duty 60s
7 = In Duty 5mn
40522 118
AFN 23 Ramp Cong 0 = ART-DI 0 = ART-DI
1 = ART-F/R
2 = ART-Frq
3 = ART-Strt/RS
4 = S-Curve
5 = ART-DI CTS
6 = ART-F/R CTS
7 = ART-Frq CTS
8 = ART-Strt/CS
9 = S-Curve CTS
40523 120
AFN 24 Accel Time 2 3.0 sec 0.1 to 3200.0 sec 40524 120
AFN 25 Decel Time 2 3.0 sec 0.1 to 3200.0 sec 40525 121
AFN 26 Rmp Rounding 25% 1-100% 40526 121
AFN 27 Rmp Sw. Freq 40.0Hz 0.0 to 400.0 Hz 40527 121
AFN 28 Single Phase 0 = No
ModelDependant
0 = No
1 = Yes
40528 122
AFN 29 Ref Fault 2 = Fault 0 = Retain Spd
1 = Preset Lvl
2 = Fault
40529 122
AFN 30 Lost Ref Frq 0.0Hz 0.0 to 400.0 Hz 40530 122
AFN 31 PID Cong 0 = No PID 0 = No PID
1 = Dir F-Fwd
2 = Rev F-Fwd
3 = Dir Full
4 = Rev Full
40531 123
AFN 32 Feedback Cfg 0 = Vin1 0 = Vin1
1 = Cin
2 = Vin2
40532 123
AFN 33 PID P-Gain 0 0 to 2000 40533 123
AFN 34 PID I-Gain 0 0 to 10000 40534 124
AFN 35 PID D-Gain 0 0 to 1000 40535 124
AFN 36 PID FB Gain 1000 0 to 2000 40536 124
AFN 37 PID High Alm 0.00% 0.00 to 100.00 % 40537 125
