ID Percent AFN 16
IQ Percent AFN 17
AFN: ID Percent
16 +0.0%
AFN: IQ Percent
17 +0.0%
7 - PARAMETER DESCRIPTION
LCD Display
Range -300.0 to 300.0% (view only)
Description This parameter shows the Flux producing current (as a percentage of motor rated current) that is being
applied to the motor.
LCD Display
Range -300.0 to 300.0% (view only)
Description This parameter shows the Torque producing current (as a percentage of motor rated current) that is being
applied to the motor.
Catch Mode AFN 18
AFN: Catch Mode
18 Sweep FWD
LCD Display
Range
Parameter Value Description
Sweep Fwd (Default)
Catch Mode algorithm sweeps through frequencies only in the forward direction while
searching for the operating frequency.
Sweep Rev
Catch Mode algorithm sweeps through frequencies only in the reverse direction while
searching for the operating frequency.
Sweep F/R
Catch Mode algorithm sweeps through frequencies in both directions while searching for the
operating frequency. The direction that is chosen rst depends on the direction of the
command given to the drive. Note that this option is slower than the other two modes of
operation.
Description This parameter congures how the Catch Mode operates when selected in FUN 03 (Start Mode).
z NOTE: This feature is disabled if a digital input congured for “Fly Dis” is active.
See also I/O 01 through I/O 06 on page 97.
FUN 03 on page 83.
