123

SinglePhase AFN28

Ref Fault AFN 29

AFN: Single Phase

28 No

AFN: Ref Fault

29 Fault

7 - PARAMETER DESCRIPTION

LCD Display

Range Yes

No (Default)

Description Selecting yes will allow the drive to function on single phase input power. If this parameter is set to No,

the drive will fault on “Phase Loss” when single phase power is applied. Consult factory before using a

drive on single phase power.

See page 34 for more information on single phase.

LCD Display

Range

Description This parameter congures what action is taken, if any, when the drive loses the reference speed input

signal (Vin1, Cin, Vin2). The input signal needs to be congured as a 4-20mA input. A Fault 22, Ref Loss

will result when the signal is at or below the trip level of 3.0 mA. When congured to a 0 - 20mA or a

0 - 10V input, the monitoring/fault is not active. Also, if the input signal (Vin1, Cin, Vin2) is congured

for broken wire detection and the input is disconnected, a fault 23, broken Wire will result.

Displayed Name Action taken when signal is lost

Retain Spd The last known reference speed will remain in effect.

Preset Lvl The drive will ramp to the frequency set by parameter AFN 30 (Lost Ref Freq)

Fault (Default) A fault is generated and the drive stops.

LostRefFrq AFN30

AFN: Lost Ref Frq

30 0.0Hz

LCD Display

Range 0 to 400.0Hz (Default 0.0Hz)

Description Lost Reference Frequency. AFN 30 - Lost Ref Freq sets the frequency level used when AFN 29 - Ref

Fault is set to Preset Lvl.

BENSHAW RSi S4 Series User Manual
