66
6 - S4 PARAMETER GROUPS
Code Parameter Name Default Range (Options) Modbus
View
Only
Page
FUN 12 Curr Lim M\R 120% 5 to 200 % 40112 88
FUN 13 Curr Lim R/F 80% 5 to 200 % 40113 88
FUN 14 Curr Lim R\R 0% 5 to 200 % 40114 88
FUN 15 Curr Lim Frq 3.0Hz 0.0 to 400.0 Hz 40115 89
FUN 16 Ramp Time CL 1.0 sec 0.1 - 3200.0 sec 40116 89
FUN 17 Curr Lim Min 10% 0 - 50% 40117 89
FUN 18 Reg Time-Out 300% 100% to 1000% 40118 89
FUN 19 Skip Frq Bnd 0.2Hz 0.2 - 20.0Hz 40119 90
FUN 20 Skip Freq 1 0.0Hz 0.0 - 400.0 Hz 40120 90
FUN 21 Skip Freq 2 0.0Hz 0.0 - 400.0 Hz 40121 90
FUN 22 Skip Freq 3 0.0Hz 0.0 - 400.0 Hz 40122 90
FUN 23 Skip Freq 4 0.0Hz 0.0 - 400.0 Hz 40123 90
FUN 24 Fault LO # 0 0 to 8 40124 90
FUN 25 Auto Rst Tm 60.0 s 0 to 60.0 s 40125 91
FUN 26 Curr Level 1 0% 0 to 200 % 40126 91
FUN 27 Curr Level 2 0% 0 to 200 % 40127 91
FUN 28 Torque Lvl 1 0% 0 to 200 % 40128 91
FUN 29 Torque Lvl 2 0% 0 to 200 % 40129 91
FUN 30 Freq Level 1 0.0Hz 0.0 - 400.0 Hz 40130 91
FUN 31 Freq Level 2 0.0Hz 0.0 - 400.0 Hz 40131 91
FUN 32 Freq Level 3 0.0Hz 0.0 - 400.0 Hz 40132 91
FUN 33 Low Freq Thr 0.0Hz 0.0 - 400.0 Hz 40133 92
FUN 34 Timer 1 Type 0 = On Delay 0 = On Delay
1 = Off Delay
2 = On/Off Delay
40134 92
FUN 35 Timer 1 Time 1.0 s 0.0 to 320.0 s 40135 92
FUN 36 Timer 2 Type 0 = On Delay 0 = On Delay
1 = Off Delay
2 = On/Off Delay
40136 93
FUN 37 Timer 2 Time 1.0 s 0.0 to 320.0 s 40137
93
FUN 38 Status Field 0 = Drive Load 0 = Drive Load
1 = Output Curr
2 = Out Volt
3 = Drive Temp
4 = % of FLA
5 = Out Power
40138
93
FUN 39 Password 0 0 to 999 40139
94
FUN 40 Display Mode 0 = Std Disply 0 = Std Disply
1 = Output Freq
2 = Stator Freq
3 = User Units
4 = RPM Units
5 = GPM Units
6 = FPM Units
7 = MPM Units
8 = PSI Units
9 = Degrees C
10 = Degrees F
11 = Time hrs
12 = Time min
13 = Time sec
14 = Fbk RPM
15 = Fbk PSI
16 = Fbk GPM
17 = Fbk User
40140
94
FUN 41 Units Scale 18000 1 to 65535 40141
95
FUN 42 Units RPM-1 Alpha-Numeric 40142
95
