AutoRstTm FUN25
FUN: Auto Rst Tm
25 60sec
7 - PARAMETER DESCRIPTION
LCD Display
Range 0 - 60 seconds (Default 60s)
Description Auto Restart Time. This parameter species the time delay before the fault is reset when automatic
resetting of faults enabled by FUN 24-Fault Lo #.
z NOTE: If this parameter is set to 0, no automatic fault resets will occur.
CurrLevel1&2 FUN26,27
TorqueLvl1&2FUN28,29
Freq Lvl 1–3 FUN 30,31,32
FUN: Curr Level 1
26 0%
FUN: Curr Level 2
27 0%
FUN: Torque Lvl 1
28 0 %
FUN: Torque Lvl 2
29 0 %
FUN: Freq Level 1
30 0.0 Hz
FUN: Freq Level 2
31 0.0 Hz
FUN: Freq Level 3
32 0.0 Hz
LCD Display
Range 0 to 200% (Default 0%)
Description Current Level parameter is a comparator between the nominal drive output current and the value entered
into the Curr Level. When the nominal drive output current exceeds this set level, the associated digital
output will be activated. The digital outputs are congured in I/O 08-I/O 11 on page 98.
LCD Display
Range 0 to 200% (Default 0%)
Description Torque Level parameter is a comparator between the load torque and the value entered into the
Torque Lvl. When the nominal drive torque exceeds this set level, the associated
digital output will be activated. The digital outputs are congured in I/O 08-I/O 11 on page 98.
LCD Display
Range 0.00 to Max Freq (Default 0.00 Hz)
Description Frequency Level parameter is a comparator between the drive output frequency and the value entered into
the Freq Lvl. When the drive output frequency exceeds this set level, the associated digital output will be
activated. The digital outputs are congured in I/O 08 – I/O 11 on page 98.
