BENSHAW RSi S4 Series User Manual

95
Password FUN39
DisplayMode FUN 40
FUN: Password
39 0
FUN: Display Mode
40 Std Display
7 - PARAMETER DESCRIPTION
LCD Display
Range 0, 111–999 (Default 0)
Description The Password allows the user to control access to the programmable functions of the inverter. The initial
value of this parameter is 0, which signies that no access code is necessary. Any number between 111 and
999 may be used for an access code.
To enter an access code, re-program FUN 39 as you would any other parameter. After the new value is
stored, you have 10 minutes of free access. If you remove power and then restore it, you will need to enter
the access code to change any program parameter. If you enter an incorrect access code, the drive displays
**Wrong Code** and allows only viewing rights to the various parameters. Once the correct code is
entered, you again have 10 minutes of free access unless power is removed and restored. To disable the
access code requirement, set FUN 39 to the access code and then change it to “0”.
LCD Display
Range
Parameter Value Description
Std Display (Default)
Standard commanded frequency
Output Freq
Output frequency actually sent to the motor
Stator Freq
Frequency of the stator
User Units
Custom units display based on values in FUN 41 and FUN 42
RPM Units
Custom speed display with RPM as units, must be scaled in FUN 41
GPM Units
Custom speed display with GPM as units, must be scaled in FUN 41
FPM Units
Custom speed display with FPM as units, must be scaled in FUN 41
MPM Units
Custom speed display with MPM as units, must be scaled in FUN 41
PSI Units
Custom speed display with PSI as units, must be scaled in FUN 41
Degrees C
Custom display with degrees C, must be scaled in FUN 41
Degrees F
Custom display with degrees F, must be scaled in FUN 41
Time hrs
Custom display time in hours of operation, must be scaled in FUN 41
Time min
Custom display time in minutes of operation, must be scaled in FUN 41
Time sec
Custom display time in seconds of operation, must be scaled in FUN 41
Fbk RPM
Display is scaled to read in RPM based on the PI feedback input to an analog input
Fbk PSI
Display is scaled to read in PSI based on the PI feedback input to an analog input
Fbk GPM
Display is scaled to read in GPM based on the PI feedback input to an analog input
Fbk User
Display is scaled to read in User units (FUN 40) based on the PI feedback input to an analog input
Description Display Mode determines how the reference or output of the drive will be displayed to the operator.
FUN 41 - Units Scale and FUN 42 -Units allow calibration of display to match actual process conditions.
