BENSHAW RSi S4 Series User Manual

28
3 - INSTALLATION
Heat Dissipation for Models Entirely Inside an Enclosure at 600VAC
RSi S4
Model
Required Dissipation for Models Entirely
Inside an Enclosure at Rated Current, 3KHz
Carrier Frequency (Watts)
Required Dissipation when Fins are
External to the Enclosure
RSi001S46W 32 15
RSi002S46W 50 22
RSi003S46W 66 21
RSi005S46W 112 33
RSi007S46W 159 37
RSi010S46W 187 54
RSi015S46W 334 124
RSi020S46W 431 143
RSi025S46W 528 154
RSi030S46W 597 155
RSi040S46W 742 160
RSi050S46W 877 170
RSi060S46W 766 200
RSi075S46W 913 200
RSi100S46W 1542 275
RSi125S46D 1988 337
RSi150S46D 2282 349
RSi200S46D 3043 355
Dissipation at rated current and maximum switching frequency.
