BENSHAW RSi S4 Series User Manual

40
4 - CONNECTIONS
z NOTE: (Asterisked size 0 S4 model numbers cannot have external braking added)
Model
Frame
Size
HP KW
Std
Resistance
Qty
Standard
DB
% of
Drive
Min. Allowed
Res.
Max. Peak
Watts
Max.Ext.
DB% of
Drive
RSi075S44W 4 75 55 60 4x60 18% 10 60,840 109%
RSi100S44W 4 100 75 60 4x60 14% 10 60,840 82%
RSi125S44D 5 125 90 60 4x60 11% 10 60,840 65%
RSi150S44D 5 150 110 60 4x60 9% 10 60,840 54%
RSi200S44D 5 200 132 60 4x60 7% 10 60,840 41%
RSi001S46W 1 1 .75 120 2x60 1058% 110 8,607 1154%
RSi002S46W 1 2 1.5 120 2x60 529% 110 8,607 577%
RSi003S46W 1 3 2.2 120 2x60 353% 110 8,607 385%
RSi005S46W 1 5 3.7 120 2x60 212% 110 8,607 231%
RSi007S46W 1 7 5.5 120 2x60 141% 91 10,404 186%
RSi010S46W 1 10 7.5 120 2x60 106% 91 10,404 139%
RSi015S46W 2 15 11 120 2x60 71% 62 15,269 136%
RSi020S46W 2 20 15 120 2x60 53% 62 15,269 102%
RSi025S46W 2 25 18 120 2x60 42% 62 15,269 82%
RSi030S46W 2 30 22 120 2x60 35% 62 15,269 68%
RSi040S46W 3 40 30 60 4x60 53% 24 39,447 132%
RSi050S46W 3 50 37 60 4x60 42% 24 39,447 106%
RSi060S46W 4 60 45 60 4x60 35% 15 63,115 141%
RSi075S46W 4 75 55 60 4x60 28% 15 63,115 113%
RSi100S46W 4 100 75 60 4x60 21% 20 63,115 85%
RSi125S46D 5 125 90 60 4x60 17% 10 94,672 102%
RSi150S46D 5 150 110 60 4x60 14% 10 94,672 85%
RSi200S46D 5 200 132 60 4x60 11% 10 94,672 63%
