BENSHAW RSi SG Series User Manual

Chapter 6 - Parameter Description [FUN]
6-23
FUN-81: Analog Stall Source
FUN-82: Current Limit Level
When FUN-70 (Stall Mode) is set to “yes” user can
select a remote variable source (I, V1, Pulse) to limit
current instead of a fixed level (FUN-71). The FUN-
82 percentage is at the maximum of the analog signal
(FUN-81).
FUN-81
Setting Range
Description
None Uses FUN-71 level.
I
0(4)-20 mA signal used for
current limit.
V1
0-10V signal used for current
limit.
Pulse
0-100kHz signal used for
current limit.
Ex) FUN-81 set to “V1”, 0 - 10V scale
FUN-82 set to 150% (10V = 150%)
With 5V input at V1:
Stall level = 150% x 5V/10V = 75%
Current is limited to 75% of DRV-05, motor amps.
The calculated stall level is displayed in FUN-71.
FUN ► AnaStall Src
81 None
FUN ►Max Ana Perc
82 100%
