Chapter 4 - Operation
4-2
4.1.2 DetailedDescription
LCD Keypad Display
DRV T/K 0.0 A
00 STP 0.00 Hz
Displays Description
1) Parameter Group Displays the parameter group. There are DRV, FUN, AFN, I/O, and APP groups.
2) Run/Stop Source
Displays the control source for the drives run command.
K: Run/Stop using FWD, REV buttons on keypad
T: Run/Stop using control terminal input FX, RX
R: Run/Stop using Modbus
O: Run/Stop via option board
3) Frequency Setting
Source
Displays the source of the drive's frequency command.
K: Frequency setting using keypad
V: Frequency setting using V1 (0 ~12V) or V1 + I terminal
W: Frequency setting using V1S (-12~ 12V)
I: Frequency setting using I (4 ~ 20mA) terminal
P: Frequency setting using Pulse input
R: Frequency setting using RS-485, Modbus-RTU
U: Up terminal input when Up/Down operation is selected
D: Down terminal input when Up/Down operation is selected
S: Stop status when Up/Down operation is selected
O: Frequency setting via Communication Option board
J: Jog terminal input
1 ~ 15: Step frequency operation (except Jog)
4) Output Current Displays the Output Current during operation.
5) Parameter Number
Displays the parameter number. Use the ▲(Up), ▼(Down) key to move through the parameters.
6) Operating Status
Displays the operation information.
STP: Stop Status
FWD: During Forward operation
REV: During Reverse operation
DCB: During DC Braking
LOV: Loss of Analog Frequency Reference (V1: 0~12V, -12~12V)
LOI: Loss of Analog Frequency Reference (I: 4~20mA)
LOA: Loss of Pulsed Reference Input
LOR: Loss of Reference from Communications Option Board (Communication network fault)
Over Lap (flashing): More than one digital input is programmed to the same function.
7) Drive Output Frequency/
Command Frequency
Displays the Output Frequency during run.
Displays the Command Frequency during stop.
2) Run/Stop Source
3) Frequency Setting Source
4) Output Current
7) Drive Output Frequency During Run,
Command Fre
uenc
Durin
Sto
6) Operating Status
5) Parameter Number
1) Parameter group
