Chapter 2 – Drive Ratings and Specification
2-2
2.3 Ratings460V(50~125HP)
4
6
0
V
RSi___SG-4B 050 060 075 100 125
Std. Duty
VT Motor
Rating
(1)
[HP] 50 60 75 100 125
[kW] 37 45 55 75 90
[A] 75 91 110 152 183
Std. Duty
CT Motor
Rating
(1)
[HP] 50 60 75 100 125
[kW] 37 45 55 75 90
[A] 68 83 100 139 167
Heavy Duty
CT Motor
Rating
(1)
[HP] 40 50 60 75 100
[kW] 30 37 45 55 75
[A] 55 66 80 111 134
Output
Rating
Frequency 0.01 ~ 120 Hz
Voltage 380 ~ 480 V
(2)
Input
Rating
Voltage 3 380 ~ 480 V (-15% ~ +10 %)
Frequency 50/60 Hz ( 5 %)
Weight
(3)
Lbs. 59.5 59.5 64 92.6 94.8
Kg 27 27 29 42 43
Protection degree IP20, UL Enclosed Type 1 for all ratings (provided with conduit box)
2.4 Ratings460V(150~700HP)
4
6
0
V
RSi___SG-4 150 200 250 350 400 500 600 700
Std. Duty
VT Motor
Rating
(1)
[HP] 150 200 250 350 400 500 600 700
[kW] 110 132 160 220 280 315 375 450
[A] 223 264 325 432 547 613 731 877
Std. Duty
CT Motor
Rating
(1)
[HP] 150 200 250 300 400 450 500 600
[kW] 90 110 132 160 220 280 315 375
[A] 204 242 302 396 501 562 670 804
Heavy Duty
CT Motor
Rating
(1)
[HP] 125 150 200 250 300 350 400 500
[kW] 90 110 132 160 220 280 315 375
[A] 164 194 240 317 401 450 536 643
Output
Rating
Frequency 0.01 ~ 120 Hz
Voltage 380 ~ 480 V
(2)
Input
Rating
Voltage 3 380 ~ 480 V (-15% ~ +10 %)
Frequency 50/60 Hz ( 5 %)
Weight
Lbs. 223 223 252 441 441 536 838 838
Kg
101 101 114 200 200 243 380 380
Protection degree
IP00, UL Open Type for all ratings
