Chapter 5 – Parameter List
5-6
5.3 AFN(AdvancedFunctionGroup)ParameterList
[AFN GROUP]
PARAM Description
LCD Keypad
Display Setting Range
Factory
Default
Adj.
During
Run Page
AFN-00
Jump Code – Program
specific parameter #, hit
enter to jump to that
parameter.
Jump code
1 - 95 40 Yes 6-25
AFN-01 Last trip 1
Last trip-1
By pressing [PROG]
and [▲] key, the
frequency, current,
and operational status
at the time of fault can
be seen.
None View Only 6-25
AFN-02 Last trip 2
Last trip-2
None View Only 6-25
AFN-03 Last trip 3
Last trip-3
None View Only 6-25
AFN-04 Last trip 4
Last trip-4
None View Only 6-25
AFN-05 Last trip 5
Last trip-5
None View Only 6-25
AFN-06 Erase trips
Erase trips
No,Yes No Yes 6-25
AFN-07 Dwell Time
Dwell time
0 - 10 secs. 0.0 No 6-25
AFN-08
(Note 19)
Dwell Frequency
Dwell freq
FUN-32 - FUN-30
Hz.
5 No 6-25
AFN-10 Frequency Jump Selection
Jump freq
No, Yes No No 6-26
AFN-11
(Note 20)
Jump Frequency 1 Low
jump Lo1 Fre
0 - AFN-12 Hz. 10 Yes
6-26
AFN-12 Jump Frequency 1 High
jump Hi1 Fre
AFN-11- FUN-30 Hz. 15 Yes
AFN-13 Jump Frequency 2 Low
jump Lo2 Fre
0 - AFN-14 Hz. 20 Yes
AFN-14 Jump Frequency 2 High
jump Hi2 Fre
AFN-13- FUN-30 Hz. 25 Yes
AFN-15 Jump Frequency 3 Low
jump Lo3 Fre
0 - AFN-16 Hz. 30 Yes
AFN-16 Jump Frequency 3 High
jump Hi3 Fre
AFN-15- FUN-30 Hz. 35 Yes
AFN-20 Power ON Start Selection
Power-on run
No,Yes No Yes
6-27
AFN-21 Restart after Fault Reset
RST restart
No, Yes No Yes
AFN-22
Instantaneous Power Failure
(IPF) restart
IPF Mode
No, Yes No No 6-28
AFN-23 Speed Search
Estimated SS
Fixed
Estimated
SS
View Only 6-28
AFN-24 Auto Fault Reset
Retry Mode
No, Yes No Yes 6-28
AFN-25
(Note 21)
Number of Auto Retry
Retry number
0 - 10 0 Yes 6-28
AFN-26
Delay Time
Before Auto Retry
Retry delay
0 - 60 secs. 1 Yes 6-28
AFN-27 Flying Percentage
Flying Perc
50 – 160% 70% No 6-29
To Next Page
