BENSHAW RSi SG Series User Manual

i
APPENDIX A- UL Marking
1. Short Circuit Rating
Suitable for use on a circuit capable of delivering not more than 100,000 A(rms) Symmetrical amperes when
protected by a breaker or fuse with an interrupt rating of not less than 100,000 A(rms).
Maximum Voltage
240V for 240V rated drives, 480V for 480V rated drives, 600V for 600V rated drives. ”
Table 1. RMS Symmetrical Amperes for SG series drive.
Drive Model Rating
RSi007SG-2B, RSi007SG-4B, RSi007SG-6B, RSi010SG-2B, RSi010SG-4B,
RSi010SG-6B, RSi015SG-2B,RSi015SG-4B, RSi015SG-6B, RSi020SG-2B,
RSi020SG-4B, RSi020SG-6B, RSi025SG-2B, RSi025SG-4B, RSi025SG-6B,
RSi030SG-2B, RSi030SG-4B, RSi030SG-6B, RSi040SG-2B, RSi040SG-4B,
RSi040SG-6B, RSi050SG-4B, RSi050SG-6B, RSi060SG-4B, RSi060SG-6B,
RSi075SG-4B, RSi075SG-6B, RSi100SG-4B, RSi100SG-6B, RSi125SG-4B,
RSi125SG-6B, RSi150SG-4, RSi150SG-6, RSi200SG-4, RSi250SG-4,
RSi350SG-4, RSi400SG-4, RSi500SG-4
RSi600SG-4, RSi700SG-4
100,000A
2. Short Circuit Fuse/Breaker
UL Listed Semiconductor Input Fuses or a UL Listed Breaker Only. See the table below for the required Voltage
and Current rating of the fuses and breakers.
Input
Voltage
Model Number
RSi-xxx-SG
External Input Fuse External Breaker
Current [A] Voltage [V] Current [A] Voltage [V]
230V
Class
007SG-2B 40 500 30 230
010SG-2B 60 500 40 230
015SG-2B 80 500 60 230
020SG-2B 100 500 80 230
025SG-2B 125 500 100 230
030SG-2B 150 500 125 230
040SG-2B 200 500 150 230
460V
Class
007SG-4B
20 500 15 460
010SG-4B
30 500 20 460
015SG-4B
40 500 30 460
020SG-4B
60 500 40 460
025SG-4B
70 500 50 460
030SG-4B
80 500 60 460
040SG-4B
100 500 80 460
