6-1
Chapter6. ParameterDescriptions
6.1 DriveGroup[DRV]
DRV-00: Command Frequency / Output Current
1) Digital frequency setting
This parameter is used to set the command frequency
when DRV-04 [Frequency Mode] is set to Keypad-1 or
Keypad-2. It can be set to a value equal to or less than
FUN-30 [Maximum Frequency].
2) Monitoring function setting
The command frequency is displayed during stop.
Output current and frequency are displayed during run.
When DRV-04 [Frequency Mode] is set to V1, V1S, I,
V1+ I or Pulse the drive will display the reference
frequency during stop.
If PID control is active the user can change the units to
be displayed in I/O-86.
When DRV-17 [Speed Unit Selection] is set to Rpm,
the display will show RPM rather than Hz.
DRV-01, 02: Accel/Decel Time
The acceleration time is the amount of time that it takes
(from zero Hz.) for the drive to reach the maximum
frequency set in FUN-30 when the drive receives a
start command. The deceleration time is amount of
time the drive takes to stop from the maximum
frequency in FUN-30 to 0Hz when a stop command is
given.
When FUN-73 is set to “Delta Frequency”, the
acceleration and deceleration time is the time taken to
reach a target frequency (instead of the maximum
frequency) from a specific frequency.
Note: Set the Accel time more than 0.5 sec for
smooth acceleration. Setting it too short may
deteriorate the starting performance.
DRV-03: Drive Mode (Run/Stop Method)
This parameter selects the source of run/stop command.
LCD
Setting Range
Description
Keypad Run/Stop control by Keypad.
Fx/Rx-1
Run/Stop control by Control
Terminals FX, RX. (Method 1)
FX: Two wire contact for forward
Run/Stop
RX: Two wire contact for reverse
Run/Stop
Fx/Rx-2
Run/Stop control by Control
Terminals FX, RX. (Method 2)
FX: Two wire for Run/Stop
command
RX: Two wire for Forward/Reverse
selection (Open-Fwd, Closed-Rev)
Int. 485 Run/Stop control by Modbus.
DRV
►
Acc. time
01 20.0 sec
Factory Default: 20.0 sec
DRV
►
Dec. time
02 30.0 sec
Factory Default: 30.0 sec
DRV
►
Drive mode
03
Fx/Rx-1
Factory Default: Fx/Rx-1
DRV
►
T/K 0.0A
00 STP 0.00 Hz
Factory Default: 0.00 Hz
