BENSHAW RSi SG Series User Manual

Chapter 5 – Parameter List
5-16
5.5 APP(ApplicationGroup)ParameterList
[APP GROUP]
PARAM Description
LCD Keypad
Display Setting Range
Factory
Default
Adj.
During
Run Page
APP-00
Jump Code – Program a
specific parameter #, hit
enter to jump to that
parameter
Jump code 1
1 ~ 97 Yes Yes 6-61
APP-01
(Note 28)
Application Mode
Selection
App mode
None
MMC
None No 6-61
APP-02 PID Operation Selection
Proc PI mode
No, Yes No No 6-61
APP-03
(Note 29)
PID F Gain Selection
PID F-gain
0 - 999.9 % 0.00 Yes 6-66
APP-04 PID Auxiliary Reference
Mode Selection
Aux Ref Mode
No
Yes
No No 6-66
(Note 30)
APP-05
(Note 31)
PID Auxiliary Reference
Signal Selection
Aux Ref Sel
Keypad-1
Keypad-2
V1
V1S
I
V1+I
Pulse
Int. 485
Ext. PID
V1 No 6-66
APP-06
PID Feedback Signal
Selection
PID F/B
I
V1
Pulse
0 (I) No 6-66
APP-07 P Gain for PID Control
PID P-gain
0 - 999.9 % 1.00 Yes 6-66
APP-08 I Gain for PID Control
PID I-time
0 - 32.0 sec 10.0 Yes 6-66
APP-09 D Gain for PID Control
PID D-time
0 -100 msec 0.0 msec Yes 6-66
APP-10
High Limit Frequency for
PID Control
PID limit-H
0.00 - 300.00 Hz 60 .00 Yes 6-67
APP-11
Low Limit Frequency for
PID Control
PID limit-L
Start Freq
- 300.00 Hz
0.5 Yes 6-67
APP-12 PID Output Scale
PID Out Scale
0.0 - 999.9 % 100.00 No 6-67
APP-13 PID P2 Gain
PID P2-gain
0.0 - 999.9 % 100.00 No 6-67
APP-14 P Gain Scale
P-gain Scale
0.0 - 100.0 % 100.00 No
6-67
APP-15 PID Output Inverse
Out inverse
No
Yes
No No
APP-17
PID U curve feedback
select
PID U Fbk
No
Yes
No No
APP-20
(Note 32)
2nd Acceleration Time
2nd Acc time
0 - 6000 sec 5 Yes 6-68
