BENSHAW RSi SG Series User Manual

2-1
Chapter2. DriveRatingsandSpecification
2.1 Ratings230V(7.5~40HP)
2
3
0
V
RSi___SG-2B 007 010 015 020 025 030 040
Std. Duty VT
Motor Rating
(1)
[HP] 7.5 10 15 20 25 30 40
[kW] 5.5 7.5 11 15 18.5 22 30
[A] 24 32 46 60 74 88 115
Std. Duty CT
Motor Rating
(1)
[HP] 7.5 10 15 20 25 30 40
[kW] 5.5 7.5 11 15 18.5 22 30
[A] 22 29 42 55 67 80 105
Heavy Duty
CT Motor
Rating
(1)
[HP] 5 7.5 10 15 20 25 30
[kW] 3.7 5.5 7.5 11 15 18.5 22
[A] 17 23 33 44 54 68 84
Output
Rating
Frequency 0.01 ~ 120 Hz
Voltage 200 ~ 240 V
(2)
Input
Rating
Voltage 3 200 ~ 240 V (-15% ~ +10 %)
Frequency 50/60 Hz ( 5 %)
Weight
Lbs. 10.8 13.2 13.2 28.7 29.8 44.1 44.1
Kg 4.9 6 6 13 13.5 20 20
Protection degree IP20, UL Enclosed Type 1 for all ratings (provided with conduit box)
2.2 Ratings460V(7.5~40HP)
4
6
0
V
RSi___SG-4B 7 10 15 20 25 30 40
Std. Duty
VT Motor
Rating
(1)
[HP] 7.5 10 15 20 25 30 40
[kW] 5.5 7.5 11 15 18.5 22 30
[A] 12 16 24 30 39 45 61
Std. Duty
CT Motor
Rating
(1)
[HP] 7.5 10 15 20 25 30 40
[kW] 5.5 7.5 11 15 18.5 22 30
[A] 11 14 22 27 35 41 55
Heavy
Duty CT
Motor
Rating
(1)
[HP] 5 7.5 10 15 20 25 30
[kW] 3.7 5.5 7.5 11 15 18.5 22
[A] 8.8 12 16 22 28 34 44
Output
Rating
Frequency 0.01 ~ 120 Hz
Voltage 380 ~ 480 V
(2)
Input
Rating
Voltage 3 380 ~ 480 V (-15% ~ +10 %)
Frequency 50/60 Hz ( 5 %)
Weight
Lbs. 10.8 13.2 13.2 27.6 28.7 44.1 44.1
Kg 4.9 6 6 12.5 13 20 20
Protection degree IP20, UL Enclosed Type 1 for all ratings
