BENSHAW RSi SG Series User Manual

Chapter 5 – Parameter List
5-3
5.2 FUN(FunctionGroup)ParameterList
[FUN GROUP]
PARAM Description
LCD Keypad
Display Setting Range
Factory
Default
Adj.
During
Run Page
FUN-00
Jump Code – Program, a specific parameter
#, hit enter to jump to that parameter.
Jump Code
0 - 74 1 Yes 6-9
FUN-01 Run Prevention
Run Prev.
None
Forward Prev.
Reverse Prev.
None No 6-9
FUN-02 Acceleration Pattern
Acc. Pattern
Linear
S-curve
U-curve
Linear No 6-9
FUN-03 Deceleration Pattern
Dec. pattern
Linear
S-curve
U-curve
Linear No 6-9
FUN-04
(Note 7)
Start Curve for S-Curve Accel/Decel Pattern
Start Curve
0 - 100 % 50 No
6-9
FUN-05 End Curve for S-Curve Accel/Decel Pattern
End Curve
0 - 100 % 50 No
FUN-10 Pre-Heat
Pre-Heat Mode
No, Yes No No
6-10
FUN-11
(Note 8)
Pre-Heat Value
Pre Heat Level
1 - 50 % 30 No
FUN-12 Pre-Heat Duty
Pre Heat Perc
1 - 100 % 100 No
FUN-20 Start Mode
Start mode
Accel
DC-Start
Flying-Start
Accel No 6-11
FUN-21
(Note 9)
Starting DC Injection Braking Time
DcSt time
0 - 60 secs. 0 No
6-11
FUN-22 Starting DC Injection Braking Value
DcSt value
0 - 150 % 50 No
FUN-23 Stop Mode
Stop mode
Decel
DC-brake
Free-run
Flux-brake
Decel No 6-12
FUN-24
(Note 10)
DC Injection Braking
On-Delay Time
DcBr Dly tim
0.10 - 60.00 secs. 0.10 No
6-13
FUN-25 DC Injection Braking Frequency
DcBr Freq
0.10 - 60.00 Hz. 5.00 No
FUN-26
DC Injection Braking
Time
DcBr time
0 - 60.00 secs. 1.0 No
FUN-27 DC Injection Braking Value
DcBr value
0 - 200 % 50 No
FUN-28 Safety Stop
Safety Stop
No, Yes No No 6-13
FUN-29 Power Source Frequency
Line Freq
60.00 Hz
40 - 120 Hz. 60.00 No 6-14
FUN-30 Maximum Frequency
Max Freq
40 - 120 Hz. 60.00 No 6-14
FUN-31 Base Frequency
Base Freq
30 - FUN-30 Hz. 60.00 No 6-14
FUN-32 Starting Frequency
Start Freq
0.01 - 10.00 Hz. 0.50 No 6-14
FUN-33 Frequency Limit Selection
Freq limit
No, Yes No No 6-15
FUN-34
(Note 11)
Low Limit Frequency
Lim Lo Freq
0 - FUN-35 Hz. 0.50 Yes
6-15
FUN-35 High Limit Frequency
Lim Hi Freq
FUN-34- FUN-30 60.00 No
FUN-40 Volts/Hz Pattern
V/F pattern
Linear
Square
User V/F
Linear No 6-15
FUN-41
(Note 12)
User V/F – Frequency 1
User Freq 1
0 - FUN-30 15.00 No
6-16
FUN-42 User V/F – Voltage 1
User volt 1
0 to 100 % 25 No
FUN-43 User V/F – Frequency 2
User Freq 2
0 - FUN-30 30.00 No
