BENSHAW RSi SG Series User Manual

Chapter 5 – Parameter List
5-4
PARAM Description
LCD Keypad
Display Setting Range
Factory
Default
Adj.
During
Run Page
FUN-44 User V/F – Voltage 2
User volt 2
0 - 100 % 50 No
FUN-45 User V/F – Frequency 3
User Freq 3
0 - FUN-30 45.00 No
6-16
FUN-46 User V/F – Voltage 3
User volt 3
0 - 100 % 75 No
FUN-47 User V/F – Frequency 4
User Freq 4
0 - FUN-30 60.00 No
FUN-48 User V/F – Voltage 4
User volt 4
0 - 100 % 100 No
FUN-49 AC Input voltage Adjustment
100 %
73 - 115 % 100 No 6-16
FUN-50
Motor Rated Voltage
(Model Dependant)
Motor Volt
0 - 600 V
230 V
460 V
575 V
No 6-16
FUN-51 Energy Save
Energy save
None
Manual
Auto
None No
6-17
FUN-52
(Note 13)
ManualSave %
Manual save%
0 - 30 % 0 Yes
FUN-54 Integrating Watt Meter
KiloWattHour
0M 0.0kWh
9999999.9 kWh 0 View Only 6-17
FUN-55 Inverter Temperature
Inv. Temp.
0 - 160 deg. Cel. View Only 6-17
FUN-56 Motor Temperature
Motor Temp.
0 - 160 deg. Cel. View Only 6-18
FUN-57 No Motor Selection
No Motor Sel
No, Yes No No 6-18
FUN-58
(Note 14)
Trip Current Level
N
o Motor Level
5 - 100 % 5 No 6-18
FUN-59 Trip Time Setting
No Motor Time
0.5 - 10.0 secs. 3.0 No 6-18
FUN-64 Overload Warning Level
OL level
30 - 110 % 110 Yes 6-18
FUN-65 Overload Warning Time
OL time
0 - 30 secs. 10.0 Yes 6-18
FUN-66 Overload Trip Selection
OLT select
No, Yes No Yes 6-19
FUN-67
(Note 15)
Overload Trip Level
OLT level
30 - 150 % 120 Yes 6-19
FUN-68 Overload Trip Delay Time
OLT time
0 - 60 secs. 60.0 Yes 6-19
FUN-69 Input/Output Phase Loss Protection
Trip select
000 - 111 Bit Set 001 Yes 6-19
FUN-70 Stall Prevention Mode Selection
Stall Mode
No, Yes No No 6-20
FUN-71
(Note 16)
Stall Prevention Level
Stall level
30 - 200 % 100 No 6-20
FUN-72 Accel/Decel Change Frequency
Acc/Dec ch F
0 - FUN-30 Hz. 0 No 6-21
FUN-73 Reference Frequency for Accel and Decel
Acc/Dec Freq
Max, Delta Max No 6-21
FUN-74 Accel/Decel Time Scale
Time scale
0.01 secs.
0.1 secs.
1 sec.
0.1 Yes 6-22
FUN-75 Up/Down Save Mode
UpDnSaveMode
No, Yes No No 6-22
FUN-76
(Note 17)
Up?Down Save Frequency
UpDnSaveFreq
0.00 – FUN-30 0 View Only
6-22
FUN-80
(Note 18)
Over Heat Warning Level
OH Warn Levl
0 – 100% 90% Yes
6-22
FUN-81
(Note 16)
Analog Stall Source
AnaStall Src
None
I
V1
Pulse
None No
6-23
FUN-82 Current Limit Level
Max Ana Perc
30 – 200% 100 No
6-23
