Chapter 9 – RS485/Modbus RTU Communications
9-7
9.5.1 Commonareaaddress0x0006
Detail description on Common area address 0x0006 (Note 1)
Bit Value R/W Name Description
0 0x01 R/W Stop Issue a Stop command (0->1)
1 0x02 R/W Forward run Issue a Forward run command via communication (0->1)
2 0x04 R/W Reverse run Issue a Reverse run command via communication (0->1)
3 0x08 R/W Fault reset Issue a Fault reset command via communication (0->1)
4 0x10 R/W Emergency stop Issue a Emergency stop command via communication (0->1)
5 Not used Not Used
6~7 R Operating command 0(Terminal),1(keypad),2(option),3(Int. 485)
8~14 R Frequency command
. When operating command is issued via Terminal, Keypad or
Option
0 : DRV-00, 1 : Not used,
2 : Multi-step speed 1, 3 : Multi-step speed 2,
4 : Multi-step speed 3 5 : Multi-step speed 4,
6 : Multi-step speed 5 7 : Multi-step speed 6,
8 : Multi-step speed 7 9 : Multi-step speed 8,
10 : Multi-step speed 9 11 : Multi-step speed 10,
12 : Multi-step speed 11, 13 : Multi-step speed 12,
14 : Multi-step speed 13, 15 : Multi-step speed 14,
16 : Multi-step speed 15,
17 :Up, 18 : Down,
19 : Up/Down Zero
20~21 : RESERVE
22 : V1, 23 : V1S, 24 : I, 25 : V1+I
26 : Pulse
27 : Sub
28 : Int. 485
29 : Option
30 : Jog
31 : PID
15 0x8000 R Network error Network malfunction
Note 1: When you modify data through the common parameters, the data is not saved. The modified data is applied
only at the present time. The data will revert to the previous value when the inverter is reset or its power is cycled
Off/On again. When you modify data through the group parameters except the common, the modified value can
be saved by changing COM-67 to “yes”. The modified value is also saved when the inverter is reset or its power
is cycled Off/On.
